Module 3: Orchestration with LangGraph.js

Managing Complexity

---

Introduction: When Simple Loops Break

In Module 2, we built agents that could use tools. But we relied on the LLM to manage the workflow autonomously with stopWhen: stepCountIs(n).

This works for simple tasks, but what about complex workflows that need:

• Conditional branching: "If the stock price is above $100, send an alert, otherwise do nothing"
• Human approval: "Before sending this email, ask me to review it"
• Persistent state: "Remember the user's preferences across multiple interactions"
• Parallel execution: "Research these 5 companies simultaneously"
• Error recovery: "If the API fails, try an alternative data source"

For these scenarios, we need stateful orchestration. Enter LangGraph.

---

3.1 Why Chains Break

The Linear Chain Problem

Traditional LLM chains follow a simple pattern:

This works until you need:

Conditional logic:

// Can't do this with simple chains:
if (stockPrice > 100) {
  sendAlert()
} else {
  logToDatabase()
}

Loops with exit conditions:

// Can't do this either:
while (!taskComplete && retries < 3) {
  result = attemptTask()
  taskComplete = evaluateResult(result)
}

Human-in-the-loop:

// Or this:
draft = generateEmail()
approval = await askHuman("Send this email?")
if (approval) {
  sendEmail(draft)
}

The Graph Solution

LangGraph treats your agent as a state machine with:

• Nodes: Functions that process state
• Edges: Connections between nodes
• Conditional Edges: Branching logic
• State: A shared object passed between nodes

      ┌─────────────┐
      │   Start     │
      └──────┬──────┘
             │
      ┌──────▼──────┐
      │  Research   │
      └──────┬──────┘
             │
      ┌──────▼──────┐
    ┌─┤  Evaluate   │
    │ └──────┬──────┘
    │        │ (good result)
    │        │
    │ ┌──────▼──────┐
    │ │   Draft     │
    │ └──────┬──────┘
    │        │
    │ ┌──────▼──────┐
    └─► Human Review◄──┐
      └──────┬──────┘  │
             │ (approved)
      ┌──────▼──────┐  │
      │    Send     │  │ (rejected)
      └──────┬──────┘  │
             │         │
      ┌──────▼──────┐  │
      │    End      │◄─┘
      └─────────────┘

---

3.2 Introduction to LangGraph

Installation

npm install @langchain/langgraph @langchain/core @langchain/openai

Core Concepts

1. State

State is a TypeScript object that flows through the graph:

interface AgentState {
  messages: BaseMessage[]
  nextAction?: string
  toolResults?: any[]
  requiresApproval?: boolean
}

2. Nodes

Nodes are functions that read and modify state:

async function researchNode(state: AgentState): Promise<Partial<AgentState>> {
  const query = state.messages[state.messages.length - 1].content
  const results = await searchWeb(query)

  return {
    toolResults: results,
    nextAction: 'analyze'
  }
}

3. Edges

Edges define the flow:

// Fixed edge: always go from A to B
graph.addEdge('research', 'analyze')

// Conditional edge: choose next node based on state
graph.addConditionalEdges(
  'evaluate',
  (state) => state.confidence > 0.8 ? 'proceed' : 'retry'
)

A Simple Graph Example

import { StateGraph } from '@langchain/langgraph'
import { BaseMessage, HumanMessage, AIMessage } from '@langchain/core/messages'

// Define state shape
interface SimpleState {
  messages: BaseMessage[]
  count: number
}

// Create nodes
async function stepOne(state: SimpleState): Promise<Partial<SimpleState>> {
  console.log('Step 1: Processing...')
  return {
    count: state.count + 1,
    messages: [...state.messages, new AIMessage('Completed step 1')]
  }
}

async function stepTwo(state: SimpleState): Promise<Partial<SimpleState>> {
  console.log('Step 2: Finalizing...')
  return {
    count: state.count + 1,
    messages: [...state.messages, new AIMessage('Completed step 2')]
  }
}

// Build the graph
const workflow = new StateGraph<SimpleState>({ channels: {} })

workflow.addNode('step1', stepOne)
workflow.addNode('step2', stepTwo)

workflow.addEdge('__start__', 'step1')
workflow.addEdge('step1', 'step2')
workflow.addEdge('step2', '__end__')

const app = workflow.compile()

// Run it
const result = await app.invoke({
  messages: [new HumanMessage('Start the process')],
  count: 0
})

console.log('Final count:', result.count)
console.log('Messages:', result.messages)

---

3.3 Building a ReACT Agent

The ReACT Pattern

ReACT = Reason + Act + Observe

1. REASON: Think about what to do
2. ACT: Execute a tool or make a decision
3. OBSERVE: Review the result
4. REPEAT until task complete

Implementation with LangGraph

import { StateGraph } from '@langchain/langgraph'
import { ChatOpenAI } from '@langchain/openai'
import { HumanMessage, AIMessage, ToolMessage } from '@langchain/core/messages'

interface ReactState {
  messages: BaseMessage[]
  nextStep: 'reason' | 'act' | 'respond' | 'end'
  toolCalls: any[]
}

// Node 1: Reasoning
async function reasonNode(state: ReactState): Promise<Partial<ReactState>> {
  const llm = new ChatOpenAI({
    model: 'gpt-5',
    temperature: 0
  })

  const response = await llm.invoke(state.messages)

  // Check if LLM wants to use a tool
  if (response.tool_calls && response.tool_calls.length > 0) {
    return {
      messages: [...state.messages, response],
      toolCalls: response.tool_calls,
      nextStep: 'act'
    }
  }

  // No tool needed, just respond
  return {
    messages: [...state.messages, response],
    nextStep: 'respond'
  }
}

// Node 2: Action (execute tools)
async function actNode(state: ReactState): Promise<Partial<ReactState>> {
  const toolMessages: ToolMessage[] = []

  for (const toolCall of state.toolCalls) {
    // Execute the tool
    const result = await executeToolByName(toolCall.name, toolCall.args)

    toolMessages.push(
      new ToolMessage({
        content: JSON.stringify(result),
        tool_call_id: toolCall.id
      })
    )
  }

  return {
    messages: [...state.messages, ...toolMessages],
    nextStep: 'reason' // Loop back to reasoning
  }
}

// Node 3: Respond
async function respondNode(state: ReactState): Promise<Partial<ReactState>> {
  return {
    nextStep: 'end'
  }
}

// Routing function
function routeNext(state: ReactState): string {
  switch (state.nextStep) {
    case 'reason': return 'reason'
    case 'act': return 'act'
    case 'respond': return 'respond'
    case 'end': return '__end__'
    default: return '__end__'
  }
}

// Build the graph
const workflow = new StateGraph<ReactState>({ channels: {} })

workflow.addNode('reason', reasonNode)
workflow.addNode('act', actNode)
workflow.addNode('respond', respondNode)

workflow.setEntryPoint('reason')
workflow.addConditionalEdges('reason', routeNext)
workflow.addConditionalEdges('act', routeNext)
workflow.addEdge('respond', '__end__')

const app = workflow.compile()

Using the ReACT Agent

const result = await app.invoke({
  messages: [
    new HumanMessage('What is the current price of Apple stock and is it a good buy?')
  ],
  nextStep: 'reason',
  toolCalls: []
})

console.log(result.messages)

What happens:

1. REASON: "I need to get Apple's current stock price"
   → Calls getStockPrice tool

2. ACT: Executes getStockPrice('AAPL')
   → Returns: { price: 178.25, change: +2.3% }

3. REASON: "I have the price. Now I need to analyze if it's a good buy"
   → Calls analyzeBuySignal tool

4. ACT: Executes analyzeBuySignal('AAPL', 178.25)
   → Returns: { signal: 'HOLD', reasoning: '...' }

5. RESPOND: "Apple is trading at $178.25, up 2.3% today.
            Based on technical indicators, I'd suggest holding..."

---

3.4 Human-in-the-Loop

Why Human Approval Matters

Some actions are too sensitive to fully automate:

• Sending emails
• Making purchases
• Posting to social media
• Deleting data

You need a pause point where the human reviews and approves.

Implementation Pattern

interface ApprovalState {
  messages: BaseMessage[]
  pendingAction?: {
    type: string
    details: any
  }
  approved?: boolean
}

// Node: Draft Email
async function draftEmailNode(state: ApprovalState): Promise<Partial<ApprovalState>> {
  const llm = new ChatOpenAI({ model: 'gpt-5' })

  const draft = await llm.invoke([
    new HumanMessage('Draft an email to the CEO summarizing our Q4 results')
  ])

  return {
    messages: [...state.messages, draft],
    pendingAction: {
      type: 'send_email',
      details: {
        to: 'ceo@company.com',
        subject: 'Q4 Results Summary',
        body: draft.content
      }
    }
  }
}

// Node: Human Review (interrupts execution)
async function humanReviewNode(state: ApprovalState): Promise<Partial<ApprovalState>> {
  console.log('\n==== PENDING ACTION ====')
  console.log('Type:', state.pendingAction?.type)
  console.log('Details:', state.pendingAction?.details)
  console.log('=======================\n')

  // In a real app, this would pause and wait for user input via UI
  const approved = await promptUser('Approve this action? (yes/no): ')

  return {
    approved: approved === 'yes'
  }
}

// Node: Execute or Cancel
async function executeNode(state: ApprovalState): Promise<Partial<ApprovalState>> {
  if (state.approved) {
    // Execute the action
    await sendEmail(state.pendingAction!.details)
    return {
      messages: [...state.messages, new AIMessage('Email sent successfully')]
    }
  } else {
    return {
      messages: [...state.messages, new AIMessage('Action cancelled by user')]
    }
  }
}

// Build graph with approval checkpoint
const workflow = new StateGraph<ApprovalState>({ channels: {} })

workflow.addNode('draft', draftEmailNode)
workflow.addNode('review', humanReviewNode)
workflow.addNode('execute', executeNode)

workflow.addEdge('__start__', 'draft')
workflow.addEdge('draft', 'review')
workflow.addEdge('review', 'execute')
workflow.addEdge('execute', '__end__')

const app = workflow.compile()

With Interrupt Pattern (Advanced)

LangGraph supports checkpoints that let you pause execution:

import { MemorySaver } from '@langchain/langgraph'

const checkpointer = new MemorySaver()

const app = workflow.compile({
  checkpointer,
  interruptBefore: ['execute'] // Pause before this node
})

// First run: executes up to 'execute' node
const result1 = await app.invoke(
  { messages: [new HumanMessage('Send summary email')] },
  { configurable: { thread_id: '123' } }
)

// Show pending action to user
console.log('Pending:', result1.pendingAction)

// User approves, resume execution
const result2 = await app.invoke(
  { ...result1, approved: true },
  { configurable: { thread_id: '123' } }
)

console.log('Final:', result2.messages)

---

Complete Example: Research Agent with Approval

import { StateGraph } from '@langchain/langgraph'
import { ChatOpenAI } from '@langchain/openai'
import { HumanMessage, AIMessage } from '@langchain/core/messages'

interface ResearchState {
  messages: BaseMessage[]
  query: string
  researchResults?: string
  draft?: string
  approved?: boolean
}

// Node 1: Research
async function researchNode(state: ResearchState) {
  console.log('Researching:', state.query)
  const results = await searchWeb(state.query)
  return {
    researchResults: results,
    messages: [...state.messages, new AIMessage(`Found ${results.length} results`)]
  }
}

// Node 2: Draft
async function draftNode(state: ResearchState) {
  const llm = new ChatOpenAI({ model: 'gpt-5' })
  const draft = await llm.invoke([
    new HumanMessage(`Summarize these research results: ${state.researchResults}`)
  ])

  return {
    draft: draft.content,
    messages: [...state.messages, draft]
  }
}

// Node 3: Review
async function reviewNode(state: ResearchState) {
  console.log('\n=== DRAFT FOR REVIEW ===')
  console.log(state.draft)
  console.log('========================\n')

  const approval = await promptUser('Approve? (yes/no): ')
  return { approved: approval === 'yes' }
}

// Node 4: Send
async function sendNode(state: ResearchState) {
  if (state.approved) {
    await sendEmail(state.draft!)
    return { messages: [...state.messages, new AIMessage('Email sent!')] }
  }
  return { messages: [...state.messages, new AIMessage('Cancelled')] }
}

const workflow = new StateGraph<ResearchState>({ channels: {} })
workflow.addNode('research', researchNode)
workflow.addNode('draft', draftNode)
workflow.addNode('review', reviewNode)
workflow.addNode('send', sendNode)

workflow.addEdge('__start__', 'research')
workflow.addEdge('research', 'draft')
workflow.addEdge('draft', 'review')
workflow.addEdge('review', 'send')
workflow.addEdge('send', '__end__')

const app = workflow.compile()

// Run
await app.invoke({
  messages: [new HumanMessage('Research Tesla Q4 earnings')],
  query: 'Tesla latest quarterly earnings report'
})

---

Visualizing Your Graph

LangGraph can generate visual diagrams:

import { drawMermaid } from '@langchain/langgraph/web'

const diagram = await drawMermaid(app.getGraph())
console.log(diagram)

Outputs a Mermaid diagram you can paste into tools like Mermaid Live Editor.

---

Key Takeaways

1. LangGraph enables stateful, complex agent workflows
2. Graphs consist of nodes (functions), edges (flow), and state (data)
3. ReACT pattern (Reason → Act → Observe) is a fundamental agent architecture
4. Human-in-the-loop adds critical oversight for sensitive actions
5. Conditional edges allow dynamic branching based on state

---

Exercise: Build a Conditional Workflow

Create an agent that:

1. Checks a stock price
2. If price > $100, draft a "BUY" alert
3. If price < $50, draft a "SELL" alert
4. Otherwise, do nothing
5. Require human approval before sending any alert

---

Next up: Module 4, where we add memory and RAG (Retrieval-Augmented Generation) to make agents truly intelligent.
